Independent third-party repair of servo and proportional valves on Wittmann Battenfeld injection molding machines: MacroPower, HM, TM, and SmartPower. Rexroth 4WRPEH and Moog D661 / D662 valves rebuilt at the component level and verified on the same hydraulic stands the shop has run since 1975.
Battenfeld and Wittmann Battenfeld machines run a few distinct hydraulic platforms. Below are four common contexts where Battenfeld valves end up at the bench.
N110
MacroPower (400-2,000 ton)
Two-platen presses. Rexroth 4WRPEH proportional valves and Moog D661 / D662 servo valves come off these machines for rebuild.
N120
HM Series (25-650 ton)
Toggle-clamp presses. Rexroth proportional valves and Moog D661 servo valves come through routinely.
N130
TM Series (45-450 ton)
Toggle-clamp general-purpose presses. Rexroth proportional valves come off these machines for rebuild.
N140
SmartPower (25-400 ton)
Servo-hydraulic machines paired with a servo-pump drive. Rexroth 4WRE proportional valves come off these for rebuild.
Each unit is opened, inspected, and rebuilt at the component level. Failed parts come from inventory or pulled off donor units. Bench verification before ship.
N210
Spool & sleeve service
Spool wear, contamination scoring, and lap restoration on Rexroth 4WRPEH, 4WRE, and Moog D661 / D662 bodies.
N220
Coil & electronics
Burned proportional coils, integrated drive cards, position sensor rebuild, and feedback-loop verification on 4WRPEH onboard electronics.
N230
Pilot & torque motor
Pilot stage cleaning, torque motor null trim on Moog D661 / D662, and feedback wire repair on closed-loop bodies.
N240
Bench testing
Flow-curve, hysteresis, frequency response (servo valves), and leak verification at operating pressure. Test data available for purchase.
N250
Donor parts pool
19,000+ unit in-house pool with legacy Rexroth and Moog bodies for older Battenfeld hardware no longer supported.
N260
Repair scope
Bench-level component work on the valve hardware. Battenfeld PLC programming and machine parameter setup stay with the customer or OEM.
Spool wear, contamination scoring on lap surfaces, sticky spool action, and internal leakage past the metering edges on Moog D661 / D662 and Rexroth 4WRPEH bodies.
Pilot & null shift
Torque motor fatigue, pilot-stage contamination, and null drift on Moog D661 / D662 servo bodies.
Coil & electronics
Burned proportional coils, failed integrated electronics on 4WRPEH cards, and erratic current-to-position behavior after voltage spikes or moisture ingress.
Seals & leakage
Hardened o-rings and dynamic seals causing internal cross-port leakage and external weeping at the body interface.
N500 Workflow
From part number to ship-back
Same four-step path through the shop whether the unit is a Rexroth 4WRPEH or a Moog D661 / D662 off any Battenfeld machine generation.
N510
Get in touch
Call or email with the part number, machine model, and a photo of the nameplate if it helps.
N520
Bench review
Tech opens the unit, inspects spool and electronics, and runs it on the hydraulic stand to confirm what failed.
N530
Cost & approval
We call back with the cost and a rough turnaround. Nothing is started without your sign-off.
N540
Repair, test, ship
Failed parts replaced from inventory or off donors, the valve verified under pressure, and shipped back.
N600 Common questions
Common questions about Battenfeld valve repair
Application-specific questions on Battenfeld hydraulics. For brand-specific FAQs, see the dedicated brand pages linked above.
What valve models come off MacroPower presses?
Rexroth 4WRPEH proportional valves and Moog D661 / D662 servo valves come off MacroPower two-platen presses (400-2,000 ton) for rebuild.
Are Battenfeld and Wittmann Battenfeld valves interchangeable?
Many valve platforms remain consistent across legacy Battenfeld and current Wittmann Battenfeld models. Control electronics and bus protocols may differ on integrated cards, so verify part numbers and control-card compatibility before swapping units between machines.
Can you work on older Battenfeld valves the OEM no longer supports?
Yes. Legacy Rexroth bodies from older HM and TM machines come through the bench. The donor pool covers most of the parts that are no longer available new.
What about machine programming or parameter setup?
That side of the work stays with the customer or the OEM. NC Servo handles the valve hardware: spools, seals, coils, and electronics at the component level. PLC programming and Battenfeld controller configuration are out of scope.
Do you provide test data with the repair?
Each repaired valve is bench-tested on the hydraulic stand before it ships. Flow-curve, hysteresis, and leak data are available for purchase.
What is the warranty?
One year on parts and workmanship for repairs and rebuilt units. Standard exclusions apply for contamination, improper installation, and out-of-spec operation. Flushing and filtering the hydraulic system before reinstalling a repaired valve is recommended.
